Hollow Concrete Brick Making Machine

Hollow concrete brick making machines are an essential tool in the construction industry, providing a reliable and efficient method for producing high-quality bricks. These machines are designed to produce hollow concrete blocks that can be used for a range of building projects, including walls, foundations, and paving.

One of the key benefits of using a hollow concrete brick making machine is the speed and efficiency with which it can produce bricks. These machines are capable of producing large quantities of hollow blocks in a relatively short amount of time, which is especially important for large-scale construction projects.

Furthermore, hollow concrete blocks are known for their durability and ability to withstand harsh weather conditions. This makes them an excellent choice for building structures that need to be able to withstand the elements over time.

In addition to their strength and durability, hollow concrete blocks also offer excellent thermal insulation properties. This means that they can help to keep buildings cool in the summer and warm in the winter, which can contribute to lower energy costs and a reduced carbon footprint.

Overall, hollow concrete brick making machines are an essential tool in the construction industry, providing a reliable and efficient means of producing high-quality building materials. With their speed, durability, and thermal insulation properties, hollow concrete blocks are an excellent choice for a wide range of building projects.

Key Specifications/Special Features:

Technical specification of QFT6-15 concrete block, brick, interlock paver, curb stone, slab, wall tile making machine specification

Capacity per mould:

6pcs/mould (Standard block: 400x200x200mm)

21pcs/mould (Solid block: 230x110x75mm)

15pcs/mould (Interlock: 225x112.5x60mm)

21pcs/mould (Holland brick: 200x100x60-80mm)

Cycle time: 12-25 seconds

Capacity per shift (8 hours): Hollow block (400x200x200mm): 8640pcs

Solid Block (230x110x75mm): 40320pcs

Interlock (225x112.5x60mm): 18000pcs

Holland brick (200x100x60-80mm): 24192pcs

Vibrating frequency: 1500~4100 r/min.

Vibrating force: 60KN

Motors power: 37.5KW

Machine dimensions: 3270X1850X3200MM

Pallet size: 850X680mm

Gross weight: about 8T

2. Advantages block, paver and curb making machine

Vibration table is designed work in high frequency and low amplitude, increase 10% block strength and reduce at least 10db noise.

Automatic Siemens control system and raw material ratio record system increase 20% efficiency

Frequency conversion technology makes each hydraulic cylinder working with changeable speed: high speed in front period and slowdown in rear period, which could reduce damage to finished block and machine/

Fault alarm system, saving 30% time in troubleshooting.

Moulds are processed with the procedures of carburizing, nitriding and quenching to make strength to HRC61, and lifespan at least 1,200,000 cycles.

3. Production line preparation:

Labor: 6~8 workers/shift

Electricity consumption: 50kW/hour

Land: 3500m2 (800m2 workshop, 500m2 raw materials storage, 600m2 wet block curing yard, 1600m2 finished block storage.)
